4MP, 200nm-1060nm Pixels CCD Camera
| Features |
| Back-illuminated CCD sensors |
| 2048 x 2048 resolution with 13.5 micron pixels |
| TEC cooling |
| High QE (peak >95%) |
| Readout noise as low as 3e- |
| Wide dynamic range (16-bit readout) |
| Designed for low-light applications |
| Built-in 512 MB buffer (4 Gb) |
| CE/FCC Cerifcation，Multi-platform SDK |
The SDK supports development languages such as C/C++, C #/VB.net, Python, Java, etc,
Third-party support including LabVIEW, MATLAB, Micro-Manager, DirectShow, and TWAIN.
| Common Specifications | |
| Product Model | UVISI134BUG |
| Sensor Model | CCD42-40 BSI |
| Spectral Range | 200nm-1060nm |
| Pixel Size | 13.5µm x 13.5 µm |
| Target size | 2.4″ |
| Resolution | 2048 x 2048 |
| Frame rate | 9fps@16bit |
| Memory | 512MB (4Gb) |
| Conversion Gain | 0.655DN/e- |
| Dynamic range | 90.5dB |
| Readout Noise | 3e- |
| Full Well Capacity | 100ke- |
| SNR | 90.5dB |
| Dark current | 250e-/s/pix@ 20℃ die temp |
| Exposure Time Range | 1us-600s |
| Gain range | 1x |
| Shutter Mode | Rolling shutter |
| Binning | Software 2×2~8×8 |
| Data interface | USB3.0 |
| Data Format | Mono 16 |
| Cooling performance | -50°C TEC cooling (ambient temperature 20°C) |
| Working temperature | -50~60℃ |
| Storage Temperature | -60~85℃ |
| Humidity | 20%-80%，no condensation |
| Lens mount | C-mount |
| Software | AttosView/ SDK |
| Certification | CE，FCC |
| Parameter | Specification |
| Dimension | 100mm × 80mm × 79.25mm |
| Item | Specification |
| 1 | DC 19V power port |
| 2 | USB 3.0 port |
| 3 | GigE port |
AttosView support all Attostek UV-VIS and SWIR cameras, it is a professional software that integrates camera control, image acquisition and processing, image browsing and analysis functions.
AttosView has the following characteristics:
- x86: XP SP3 and above; CPU support SSE2 and above
- x64: Win7 and above
ascamsdk support a variety of APIs, including: Native C/C++,.NET/C#/VB.NET, Python, Java, DirectShow, Twain, LabView, Matlab, etc. Compared with other APIs, Native C/C++ API as a low-level API is characterized by using pure C/C++ development without relying on other runtime libraries. The interface is simple and the control is flexible.
- x86: XP SP3 and above; the CPU needs to support at least the SSE2 instruction set.
- x64: Win7 and above.
- arm: Win10 and above.
- arm64: Win10 and above.
AttosTek provides extensive third-party software support for its UV-Vis cameras and SWIR cameras, facilitating rapid integration and use in various development environments. This includes SDK and demo programs for LabVIEW and MATLAB, as well as DirectShow drivers, Micromanager, and TWAIN SDK drivers. These features enable seamless compatibility with mainstream development environments and third-party software, greatly simplifying the workflow for system integration and secondary development.
Support all Attostek UV-VIS and SWIR cameras.
Click the button below to download the AttosView software.
|
AttosView Recommended System Requirements |
|
|
Operating System |
Microsoft® Windows® XP / Vista / 7 / 8 /10 /11(32 & 64 bit), Mac OSX, Linux |
|
Processor (CPU) |
≥3.0 GHz Intel Core i5 or Higher |
|
Memory (RAM) |
≥8 GB |
|
Hard Drive |
NVMe Solid State Drive (SSD) |
|
Graphics Card |
Dedicated Adapter with ≥256 MB RAM |
|
Motherboard |
USB 3.0 (-USB) Cameras: Integrated Intel USB 3.0 Controller or One Unused One Unused PCle3.0*16 Slot |
|
Connectivity |
Internet Connectivity for Driver Installation |
Q1 : What advantages does this camera have for astronomical observation?
The UVISI134BUG camera, with its multiple key features, is an ideal choice for astronomical observation. It uses a back-illuminated CCD sensor with a peak quantum efficiency of 85% at 500nm, allowing it to efficiently capture the faint signals of dim celestial objects. The readout noise is as low as 3 e⁻, and it has a dynamic range of 90.5 dB, ensuring high signal-to-noise images even in very low light. With deep cooling down to -50°C (at an ambient temperature of 20°C), thermal noise is effectively suppressed, and with a maximum exposure time of 600 seconds (10 minutes), it’s perfect for long-exposure imaging of dim objects.
Q2 : -50°C cooling, what practical benefits does it bring for imaging?
This camera comes with TEC cooling, reaching temperatures as low as -50°C (at an ambient temperature of 20°C). Its advantages in real-world use include:
Long-exposure imaging: With dark current at 250 e⁻/s/pixel at 20°C, deep cooling effectively reduces thermal noise. Combined with a maximum exposure time of 600 seconds (10 minutes), it’s great for trying to catch really faint light signals, like in astronomy or spectroscopy.
Consistent image quality: Cooling eliminates pixel drift caused by thermal noise, keeping your long-time sequence shots stable.
Reliable in high temperatures: Operating range is -50 to 60°C, so it can handle extreme environments.
Q3 : Why does this series of cameras use a non-cooled design? What are the advantages?
The SWIRNC series uses a non-cooled design with low power consumption, consuming less than 2.11 W. Compared to cooled cameras, the advantages of the non-cooled design are:
Lightweight: measuring only 33 mm × 33 mm × 38 mm and weighing just 70 g.
Low power: no TEC cooling power needed, making it perfect for battery-powered portable devices.
Plug and play: powered via USB 3.0, no external power required.
Fast startup: no need to wait for cooling to reach the target temperature.
4 MP 13.5µm Pixel Size Camera with Back-illuminated CCD sensors
UVISI134BUG
4 MP, 200nm-1060nm CCD Camera
Optional accessories – lenses
AttosView offers an optional YLGD series continuous zoom optical system for visible light cameras, designed specifically for high-precision imaging scenarios. The YLGD series continuous zoom optical system series provides multiple focal length options and is suitable for various professional applications such as security surveillance, industrial vision inspection, and scientific observation, ensuring excellent image clarity, operational flexibility, and environmental adaptability. For inquiries, please contact sales@attostek.com
